MR-J3-70B High speed serial communication between the SSCNET and the servo amplifier by using the fastest up to 044ms communication cycle, MITSUBISHI MR-J3-70B

MITSUBISHI motor universal AC servo amplifier MELSERVO-J3W series (a two axis servo amplifier).
Rated output A axis: 400w.
Rated output B axis: 400w.
Interface type: SSCNET type III fiber communication.
With the same high performance, multi functionality and practicality of the MR-J3-B servo amplifier,
Each MR-J3W-B servo amplifier can be used to rotate the servvo motor,
Combined control of any two kinds of linear servo motor and direct drive servo motor MR-J3-70B.
The installation area can be reduced by 25% to 17% compared with two MR-J3-B servo amplifiers MR-J3-70B.
Therefore, a more compact control system can be constructed.
In addition, the two axes use the same main circuit power supply, control circuit power supply and SSCNET III communication fiber, thus greatly reducing the wiring MR-J3-70B.1 axis servo amplifier.
MITSUBISHI general AC servo amplifier MELSERVO-J4 series.
Rated output: 2.0kw.
Interface: SSCNET III /H.
Power supply: three phase AC200V.
Servo amplifier supporting SSCNET III /H.
Complete synchronization system capable of using high speed serial optical communication MITSUBISHI MR-J3-70B.
Can be combined with the servo system controller to maximize the performance of the servo system.
2 low frequency vibration can be suppressed at the same time by supporting the seismic algorithm of 3 inertial equipment.
Configurator2 MR to achieve convenient adjustment MITSUBISHI MR-J3-70B.
Effectively restrain the low frequency aftershock effect produced by the front end of the boom or the main body of the device 100Hz.
Can effectively shorten the time to control the stability of the aftershock.
In the XY design of trajectory control, improve the accuracy of arc track MITSUBISHI MR-J3-70B.
At the same time, it can effectively control the phenomenon of quadrant protrusion caused by the rotation direction of the servo motor, which is caused by friction and twisting.
MITSUBISHI motor universal AC servo amplifier MELSERVO-J3 series.
Rated output: 0.75kw.
Interface type: SSCNET type III fiber communication.
Power specification: single phase AC200V.
High speed serial communication between the SSCNET and the servo amplifier by using the fastest up to 0.44ms communication cycle,
A fully synchronous control system can be constructed.
It is only necessary to insert the special optical fiber into the joint to form SSCNET III network, which greatly reduces the wiring work and reduces the possibility of false wiring.
Due to the adoption of the optical fiber communication, the anti noise ability can be greatly improved and the long distance wiring of 50 meters (maximum 800 meters x 16 axes) can be realized.
A servo amplifier to meet the full closed loop control function MR-J3-B-RJ006 MR-J3-70B.
Suitable for mechanical servo optimization and adjustment!
More advanced optimization adjustment function and control function to maximize mechanical properties.
