Proface PFXSP5B10(SP-5B10) Open host module

Analog /PNP output type.
Display size: 5.7 inches.
Resolution: 320 x 240 pixels (QVGA).
LCD:TFT.
Color: 65536 color.
Ethernet interface: 1.
Serial port: 1.
CANopen interface: 1.
USB (host):1.
USB (equipment):1.
Built in DIO input: 12 points.
Built in DIO output: 6 points PFXSP5B10(SP-5B10).
Built in AIIO input: 4 points.
Built in AIO output: 2 points.
Common DIO:2 point high speed counter (with synchronous output) pulse capture input.
Dedicated DIO:2 point pulse output, PWM output PFXSP5B10(SP-5B10).
Expansion module EX module: none.
Expansion module CANopen module: 63 stations.
Controller memory size: EPROM 132KB FLASH (equivalent to 15000 steps (up to 60000 steps) Proface PFXSP5B10(SP-5B10).
CANopen network
LT4000M supports data exchange with a variety of remote devices through the CANopen, easy to achieve economic and easy to use system design PFXSP5B10(SP-5B10).
Can choose standard I/O module, also can choose action or control module and other more advanced products in complex application Proface PFXSP5B10(SP-5B10).
Compact size.
The volume is small but the display is fresh and bright, can create a rich and readable operation picture.
The control function of the whole and the digital I/O, analog I/O, analog temperature input and USB, serial port and Ethernet communication interface Proface PFXSP5B10(SP-5B10).
Integrated design.
Adopt integrative design, compact structure,
When the installation is only required to open a hole in the panel 22mm.
The display module or the control module can be easily replaced when the fault is eliminated.
Flexible installation.
The control modulee can be installed on the DIN guide rail by using the split installation cable,
And the display module is installed in other locations PFXSP5B10(SP-5B10).
Display module occupies a small space, even if the space is limited, but also can be flexible to install.
