Product Name:Cepex enclosure
Part No.4324. alpine white
180
as panel mounted receptacle MENNEKES 180.
for installation of RJ45 data port receptacles .
2 keys.
with identical locks: part no + index G.Product Name:Receptacle
Part No.22356.
Ampere :63A.
Poles:3P.
Voltage:20-25,40-50V.
Hertz:100-200 Hz MENNEKES 180.
Earth position:4 h.
Connection technology:Screw terminals.
Contact:nickel plated contacts, highly heat resistant contact carrier.
Protection type:IP44.
highly heat resistant contact carrier.
nickel plated contacts.
internal fixing.
one cable entry at top and two blind cable entries (can be cut out) at bottom.
enclosure base can be turned 180°.
63A is not standardized.Product Name:EverGUM receptacle combination
Part No.:71044NF.
Fitted with:1 CEE 32A, 4p, 400V
1 CEE 16A, 4p, 400V
3 french/belg. standard 16A, 2p+E, 230V.
Fusing:1 MCB 32A, 3p, C
1 MCB 16A, 3p, C
3 MCB´s 16A, 1p+N, B .
Connection/feeder cable:for 2 cable up to 5 x 25mm² 180.
Enclosure size:380 x 230 mm (H x W).
Prottecction type IP44 180.
solid rubber enclosure, signal yellow RAL 1003.
pre-wired for installation.
180 Operation manual/Instructions/Model selection sample download link:
