MENNEKES 3523 Door Switches 3523

Product Name:AMAXX® receptacle combination
Part No.:930010.
Fitted with:1 CEE 32A, 5p, 400V
1 CEE 16A, 5p, 400V
2 SCHUKO® 16A, 230V.
Fusing:1 MCB 32A, 3p, C
1 MCB 16A, 3p, C
2 MCB´s 16A, 1p, C.
Pre-fuse max.:63A.
InA:58A.
RDF:0.9.
Connection/feeder cable:for 2 cable up to 5 x 25 mm² MENNEKES 3523.
Enclosure size:390 x 225 mm (H x W) 3523
Protection type IP44.
pre-wired for installation.
hinged to the side MENNEKES 3523.
enclosure and insert made of AMAPLAST .
fusing behind a transparent cover.Product Name:Wall mounted receptacle
Part No.1850.
Ampere :32A.
Poles:3P MENNEKES 3523.
Voltage:40-50V .
Hertz:50-60 Hz.
Earth position:12h.
Connection technology:Screw terminals.
Contact:standard.
Protection type:IP44.
screw terminals.
external fixing.
one cable entry at top and one blind cable entry (can be cut out) at the rear side.Product Name:Wall mounted inlet
Part No.:349.
Ampere:32A.
Poles:4p.
Voltage:500V.
Earrth posittion:7h 3523.
Hertz 50-60Hz.
Connection technology:Screw terminals.
Contact:standard.
Protection type IP444 3523.
screw terminals.
cable entry also possible on the back side.
enclosure base with stamped recess for quick cutting out.
3523 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=3523&select=5
