MENNEKES 972 Door Switches 972

Product Name:Plug AM-TOP®
Part No.:257.
Ampere:16A.
Poles:5p.
Voltage:230V.
Earth position: 9h.
Hertz 50-60Hz.
Connection technology:Screw terminals.
Contact:standard.
Protection type IP44 MENNEKES 972.
screw terminals.
single part body 972
cable gland and sealing.
strain relief and protection against kinking.Product Name:Plug AM-TOP®
Part No.:20764.
Ampere:16A.
Poles:4p.
Voltage:400V.
Earth position:6h.
Hertz 50-60Hz.
Connection technology:Screw terminals MENNEKES 972.
Contact:nickel plated contacts, highly heat resistant contact carrier .
Protection type IP67.
screw terminals.
single part body.
highly heat resistant contact carrier.
nickel plated contacts.
cable gland and sealing.
strain relief and protection against kinking MENNEKES 972. Product Name:Wall mounted receptacle
Part No . :1420.
Ampere:32A.
Poles:3p.
Voltage:110V.
Earth position:4h.
Hertz:50-60 Hz.
Connection technology:Screw terminals.
Contact:standard.
Protection type:IP44.
screw terminals.
internal fixing.
one cable entry at top, two blind cable entries (can be cut out) at bottom.
enclosure base can be turned 180°.
receptacles are designed for adding an auxiliary contact switch.Product Name:Cepex wall mounted receptacle
Part No.:4162.
Ampere:16A.
Poles:3p.
Voltage:230V.
Earth position: 6h.
Hertz 50-60Hz.
Protection type IP44.
screw terminals.
with labelling field.
with safety lock.
two keys.
cannot be dismantled when locked.
on request with identical locks.
cable entry: 1 x M 25 with cable gland at top, 1 x M 25 to be cut out at the bottom, 1 x M 20 to be cut out at the back side, for cables 7 up to 13 mm Ø.Panel socket with TwinCONTAACT duall connection terminal 972.
Screw free spring terminal.
Resistance to chemical corrosion.
Suitable for T connection.
With 2 external fixation holes.
Housing base can rotate 180 degrees.
Socket can be fitted with auxiliary contacts.
Current: 16A.

Poole number: 4p 972.
Voltage: >50-500V.
Location: 2h hour.
Hz: >300-500Hz.
Connection: free screw - TwinCONTACT.
Contact: standard.
Protection level: IP67.
972 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=972&select=5
