MENNEKES Door Switches 1486

Product Name:AMAXX® receptacle combination
Part No.:940012.
Fitted with:1 CEE 32A, 5p, 400V
2 CEE 16A, 5p, 400V
4 SCHUKO® 16A, 230V.
Fusing:1 MCB 32A, 3p, C
2 MCB´s 16A, 3p, C
4 MCB´s 16A, 1p, C.
Pre-fuse max.:100A.
InA:72A
RDF:0.75.
Connection/feeder cable:for 2 cable up to 5 x 25 mm² MENNEKES Door Switches.
Enclosure size:520 x 225 mm (H x W) 1486
Protection type IP44.
pre-wired for installation.
hinged to the side MENNEKES Door Switches.
enclosure and insert made of AMAPLAST .
fusing behind a transparent cover.Product Name:Receptacles
Part No.:21464.
Ampere:16A.
Poles:4p.
Voltage:500V.
Earth position:7h.
Hertz50-60 Hz.
Connection technology:Screw terminals MENNEKES Door Switches.
Contact:standard.
Protection type:IP67.
screw terminals.
with highly heat resistant contact carrier .
nickel plated contacts.
with 4 external fixing holes.
one cable entry at top, one blind cable entry (can be cut out) at bottom.Product Name:Panel mounted receptacle with TwinCONTACT
Part No.:1646.
Ampere:16A.
Poles:5p.
Voltage:>50-500V.
Earth position :2h.
Hertz>300-500 Hz.
Connection technology:Screwless - TwinCONTACT.
Contact: standrad.
Protection type IP44 .
screwless spring terminals.
suitable for through wiring.
flange: 73,5 x 64 mm.
fixing hole spacing: 60 x 52 mm.
20° inclination.Product Name:Wall mounted receptacle
Part No.75271.
Ampere :200A.
Poles：4P.
Voltage:400V.
Earth position:6 h.
Hertz:50-60 Hz.
Connection technology:Screw terminals.
Contact:standard.
screw terminals MENNEKES 1486.
switched.
mechanical interlock.
cable entry bushing for cables of uup to 65 mm at top and blind flange at bottom MENNEKES 1486.
enclosure made of sheet steel, painted in RAL 1021.
seawater resistant products are available on request.
