Proface GP3000H-WMA-01

Direct interface Matsushita Electric PLC FP series CPU port.3.5 inch screen protective cover (1 pieces)Specifications: DC24/S (standard) class models.
Display type: TFT color LCD (Gao Liangdu).
Display size: 7.5 inches.
Resolution: 640 x 480 pixels (VGA).
Display color: 65536 color (no flicker) /16384 color (flashing) Proface .
Brightness adjustment: 8 level adjustment can be carried out by touch panel.
Touch panel type: resistance type (analog) GP3000H-WMA-01
Error visualization.
The controller is directly connected to the GP, and the key error information of the controller can be displayed on the GP by using the sample unit.
Easily upgrade Proface .
GP/ST series supports GP series of all models of the screen data, including the first generation of the GP10 series .
GP product family to maintain the size of the opening of the panel compatibility, to facilitate easy replacement.
Simulated running status on PC.
Use PC simulation function, do not need to transfer the picture to GP,
You can check all the functions of GP on the PC - including the screen operation, D script, logical script Proface .
Rich sample images can reduce programming time .
Pro-face provides a large number of sample images and 3D parts,
So you can easily create a beautiful and intuitive picture, in order to save editing time.
Can improve the efficiency of the 5 functions.
Using EX GP-Pro can easily create a clear picture and save the creation time.
Screen and logic programming software EX GP-Pro interface is very friendly,
The drag and drop feature makes the software interface easy to operate.
EX GP-Pro powerful features, such as 3D simulation components, image fonts and simulation functions,
Even beginners can easily and quickly grasp how to create a picture. Disposable film (5 sheets / sets) for protecting screen against contamination of human computer interface.DIO model /PNP output type.
Display size: 3.5 inches.
Resolution: 320 x 240 pixels (QVGA).
LCD:TFT.
Color: 65536 color.
Ethernet interface: 1.
Serial port: 1.
CANopen interface: 1.
USB (host):1.
USB (equipment):1.
Built in DIO input: 20 points.
Built in DIO output: 10 points.
Built in AIO input: No.
Built in AIO output: No.
Common DIO:2 point high speed counter (with synchronous output) pulse capture input.
Dedicated DIO:2 point pulse output, PWM output.
Expansion module EX module: none.
Expansion module CANopen module: 63 stations.
Controller memory size: EPROM 132KB FLASH (equivalent to 15000 steps (up to 60000 steps).
Remote HMI Pro-face.
Natural connection production line and tablet PC or smart phone. By adding APP,
True implementation of mobile operations without loss of any operational performance.
Directly confirm the cause of the failure of the phone, as far as possible not to the scene on the recovery of the machine running.
CANopen network
LT4000M supports data exchange with a variety of remote devices through the CANopen, easy to achieve economic and easy to use system design.
Can choose standard I/O module, also can choose action or control module and other more advanced products in complex application.
Compact size.
The volume is small but the display is fresh and bright, can create a rich and readable operation picture.
The control function of the whole and the digital I/O, analog I/O, analog temperature input and USB, serial port and Ethernet communication interface.
Integrated design.
Adopt integrative design, compact structure,
When the installation is only required to open a hoole in the panel 22mm .
Thee display module or the control module can be easily replaced when the fault is eliminated Proface GP3000H-WMA-01.
Flexible installation.
The control module can be installed on the DIN guide rail by using the split installation cable,
And the disspllay module is installed in other locations Proface GP3000H-WMA-01.
Display module occupies a small space, even if the space is limited, but also can be flexible to install.
GP3000H-WMA-01 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=GP3000H-WMA-01&select=5
