Proface LT3300-S1-D24-K LT3300-S1-D24-K

Type: there is an emergency stop switch (red), no key switch.
Display type: TFT color LCD.
Display size: 5.7 inch.
Display color: 65536 color (no flicker), 16384 color (flashing).
Resolution (pixel) x:640 480 (VGA).
Memory: 32MB.
Data backup: 320KB SRAM.
Emergency stop switch provides 3 colors of red, yellow and grey Proface LT3300-S1-D24-K.
3 position enable switch with forced contact disconnect function.
Key switch without pressing the emergency stop switch can also be mobile devices LT3300-S1-D24-K
Very light.
The high visibility of the configuration of the 65536 color TFT color LCD.
High definition and wide viewing angle to bring excellent visual effects Proface LT3300-S1-D24-K.
Easily replace GP3000H series.USB cable fastening clip (Type-A) for preventing disconnection of connection (5 / set) . For 3.8 inch models, connect the connector to the DIO interface. For connecting external I/O devices. (5 / set)When the man-machine interface is installed to the fixed panel to provide dust proof and moisture proof function. (1)Screen size: 7.4 inches.
Display type: TFT color LCD Proface LT3300-S1-D24-K.
Display color: 256 color (no flash) /64 color (3 speed flicker).
Backlight: CCFL (service life: more than 50000 hours, 24 hours of continuous work) .
Resolution: 640 x 480 pixels.
Brightness control: 4 level adjustment can be carried out by touch panel.
Voltage: DC24V.
Internal memory: FLASH EPROM 4MB.
Backup memory: 256KB SRAM.
Interface: Ethernet, CF card. Connect to PC, transfer screen data and user programs.LT4000M (module type analog), PNP output, DC24V (host).A veneer, for the GP4000 series back loading models of full flush (white, 1)Mounting screws (4 sets) to be fitted to the hard panel at the interface of the machine.COM1 interface with the cable for direct connection to the CPU series PLC Q128MB, for the implementation of the picture save, log and data backup and other data management operations, such as compression flash memory card.LT fasteners installed on the control panel (4 / set)"Module type compact.
Input voltage: DC24V.
Screen size: 5.7 inches.
Display type (resolution):65536 color TFT display LCD (QVGA 320 x 240 pixels).
Touch panel type: analog resistance.
Memory: 8MB (internal memory), nvSRAM128KB (non-volatile, no battery).
Ethernet interface: 1.
Serial port: RS-232C * 1, RS-422/485 * 1.
SD card slot (max 32GB): No.
USB interface: Type-A x (2) USB 1, Mini-B USB (2) x 1.
Replaceable battery: no (rechargeable battery).
Alarm analysis function block: No.
Coating models: none.
The use of drag and drop operations, can be easily shared between the man-machine interface and the control program of the symbolic register data,
Make the programming process intuitive and efficient.
In addition, the common and special control function is defined as the function block, which simplifies the design of the control system. .
The man-machine iinterface picture is directly connected with the control program, which can realize the efficient programming LT3300-S1-D24-K.
6 Display Module 2 host module, can realize the 12 kinds of "intelligent platform".
Modular design, display module and thhe host module can be split,
Therefore can be replaced respectively LT3300-S1-D24-K.
Display module and host module free combination, function and size of flexible. "
LT3300-S1-D24-K Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=LT3300-S1-D24-K&select=5
