Product Name:Angled plug SCHUKO®
Part No.:10818.
Ampere :16A.
Poles:2p+E.
Voltage:230V.
Connection technology:Screw terminals
122
screw terminals.
with cable gland.
for cables up to 3 x 2 122. 5 mm², up to H07RN-F.Product Name:Panel mounted receptacle
Part No . :3060.
Ampere:16A.
Poles:5p.
Voltage:>50-500V.
Earth position :2h.
Hertz >300-500Hz.
Connection technology:Screw terminals.
Contact: standrad.
Protection type IP44.
screw terminals.
straight 122. Product Name:Snap-in receptacle SCHUKO®
Part No.:11513K.
Ampere :16A .
Poles:2p+E.
Voltage:230V.
Shutter:no.
Connection technology:Plug-in terminals.
Contact:standard.
without hinged lid.
with 3 plug-in terminals for connection of 1.5 – 2.5 mm².
for easy installation in a cable duct or an enclosure.
for fixing on DIN rail with fixing rack 11254.Product Name:AMAXX® receptacle combination
Part No.:930021
Fitted with:4 SCHUKO® 16A, 230V.
Fusing:1 RCD 40A, 4p, 0.03A
4 MCB´s 16A, 1p, C .
Pre-fuse max:100A.
InA :32A.
RDF:1.
Connection/feeder cable:for 2 cable up to 5 x 25mm².
Enclosure size:390 x 225 mm (H x W).
Protection type IP67.
pre-wired for installation MENNEKES 122.
enclosure and insert made of AMAPLAST MENNEKES 122.
fusing behind a transparent cover.
