Sale 530 MENNEKES 530 Door Switches

Product Name:Panel mounted inlet
Part No.:816.
Ampere:32A.
Poles:3p
Voltage:110V.
Earth position:4h.
Hertz 50-60Hz.
Connection technology:Screw terminals.
Contact:standard.
Protection type IP44 530.
screw terminals.
nickel-plated contacts 530
a retaining nose to hold the hinged lid of the connector must be provided by the customer in order to ensure satisfactory locking.Product Name:EverGUM receptacle combination
Part No.:70026.
Fitted with:6 SCHUKO® 16A, 230V.
Fusing:1 RCD 40A, 2p, 0 530. 03A.
Connection/feeder cable:2 m H07RN-F3G1 . 5 with plug SCHUKO® 16A, 230V.
Enclosure size:445 x 135 mm (H x W).
Protection type IP44.
solid rubber enclosure, signal yellow RAL 1003 530.
pre-wired for installation.Product Name:Wall mounted receptacle
Part No.:131A.
Ampere:63A.
Poles:4p.
Voltage:230V.
Earth position:9h.
Hertz50-60 Hz.
Connection technology:Screw terminals.
Contact:standard.
Protection type:IP67.
screw terminals.
with SoftCONTACT.
internal fixing.
one cable entry at top and two blind cable entries. (can be cut out) at bottom.
enclosure base can be turned 180°.
with 6 fixing points to accommodate special terminals.
products with pilot contact: part no. + index P.Product Name:Plug PowerTOP®
Part No.:3948.
Ampere:32A.
Poles:4p.
Voltage:500V.
Earth position:7h.
Hertz 50-60Hz.
Connection technology:Screw terminals.
Contact:nickel plated contacts, highly heat resistant contact carrier.
Protection type IP44.
screw terminals.
highly heat resistant contact carrier.
nickel plated contacts.
cable gland and external cable grip.Product Name:Plug PowerTOP
Part No.2600.
Ampere:32A.
Poles:4P.
Voltage:380-400V.
Earth position:3h.
Hertz:550-60 Hz .
Connecction technology :Screw terminals MENNEKES 530.
Contact:nickel plated contacts, highly heat resistant contact carrier.
Protection type:IP 67.
screw termiinaals MENNEKES 530.
highly heat resistant contact carrier.
nickel plated contacts.
cable gland and external cable grip and grommet.
contact pins sealed with gaskets.
530 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=530&select=5
