Sale AST3501-T1-AF Proface AST3501-T1-AF

Output point: 8 point transistor (PNP).
Rated output voltage: DC24V.
External connection: 10 pin terminal connector.
Public end design: 8 point /1 public end. Cable for connecting GP3000 to various modulesThe man-machine interface directly connected MITSUBISHI electric PLC Q series CPU programming port AST3501-T1-AF. For 3.8 inch models, prevent cable loose from the USB cable fastening clip (5 / set).Output points: 8 point relay (a-connect) AST3501-T1-AF
Rated output voltage.
External connection: 11 pin terminal connector.
Public end design: 4 point /1 public end. Used to install the man-machine interface to the fixed panel. (4 / set)Display size: 3 AST3501-T1-AF. 8 inches.
Display type: monochrome LCD.
Display color: black and white (2 gray level) / black and white (8 gray level) .
Backlight: LED backlight.
Resolution: 320 x 240 pixels.
Brightness control: 2 level adjustment can be carried out by touch panel.
Contrast control: 8 level adjustment can be carried out through the touch panel.
Memory: EPROM 640KB FLASH.
Serial port: RS-232C. Disposable film (5 sheets / sets) for protecting screen against contamination of human computer interfaceCable for connecting GP3000 to various modulesMemory for extending EX GP-Pro alarm and character table functions AST3501-T1-AF. Analog /NPN output type.
Display size: 3.5 inches.
Resolution: 320 x 240 pixels (QVGA).
LCD:TFT.
Color: 65536 color.
Ethernet interface: 1.
Serial port: 1.
CANopen interface: 1.
USB (host):1.
USB (equipment):1.
Built in DIO input: 12 points.
Built in DIO output: 6 points.
Built in AIO input: 4 points.
Built in AIO output: 2 points.
Common DIO:2 point high speed counter (with synchronous output) pulse capture input.
Dedicated DIO:2 point pulse output, PWM output.
Expansion module EX module: none.
Expansion module CANopen module: 63 stations.
Controller memory size: EPROM 132KB FLASH (equivalent to 15000 steps (up to 60000 steps).
Flexible installation.
The control module can be installed on the DIN guide rail by using the split installation cable,
And the display module is installed in other locations.
Display module occupies a small space, even if the space is limited, but also can be flexible to install.
Connect various control devices.
Pro-face human machine interface can be connected to a variety of industrial controllers, including PLC, motion controller, robot and other equipment.
Remote HMI Pro-face.
Natural connection production line and tablet PC or smart phone. By adding APP,
True implementation of mobile operations without loss of any operational performance.
Directly confirm the cause of the failure of the phone, as far as possible not to the scene on the recovery of the machine running.
CANopen network
LT4000M supports data exchange with a variety of remote devices through the CANopen, easy to achieve economic and easy to use system design.
Can choose standard I/O module, also can choose action or control module and other more advanced products in complex application.
Use EX GP-Pro to easily test and debug the project.
EX GP-Pro simulation is a kind of offline simulation function, with the help of this function,
No need to connect the man-machine interface, you can test the operation of the screen and the logic program.
Compact size.
The volume is small but the display is fresh and bright, can create a rich and readable opeeration picture .
The conttrol function of the whole and the digital I/O, analog I/O, analog temperature input and USB, serial port and Ethernet communication interface Proface AST3501-T1-AF.
Integrated design.
Adopt integrative design, compact structure,
When the installlattion is only required to open a hole in the panel 22mm Proface AST3501-T1-AF.
The display module or the control module can be easily replaced when the fault is eliminated.
AST3501-T1-AF Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=AST3501-T1-AF&select=5
