A6CON-P520 MITSUBISHI A6CON-P520

Motor series: low inertia, low power.
Rated output power: 0.4kw.
Rated speed: 6000r/min.
Whether with brake: No.
Shaft end: Standard (straight).
Protection level: IP55 does not include the shaft part and the connector.
Features: low inertia is particularly suitable for high speed motor (6000 or 12000 RPM / min) of general industrial machinery MITSUBISHI A6CON-P520.
Application example 1: drive belt drive, robot.
Application example 2: assembly machine, sewing machine, X-Y working table A6CON-P520
Application example 3: food manufacturing machinery, semiconductor manufacturing equipment, knitting machine and embroidery machine.
High resolution encoder 131072p/rev (17 bit) MITSUBISHI A6CON-P520.
The encoder with high resolution ensures excellent performance and stability at low speed .
All motor dimensions are the same as before and all are compatible with the wiring. MITSUBISHI inverter series: FR-A820.
Voltage level: three phase 200V.
Power: 15kw.
SLD converter rated current: 77A.
Structure and function: Standard model.
Type: CA.
Substrate coating: have.
Parameters can be selected by 4 different rated current and different overload rating (SLD (ultra light load) rated, LD (light load) rating, ND (general load) rating, HD (weight) MITSUBISHI A6CON-P520.
Type load) for selection.
You can choose the most suitable frequency converter for use; and by selecting a transducer with a SLD or LD rated level,
Be able to reduce the size of the device (compared with the FR-A700 series, to reduce the volume of equipment).
For applications that require high torque at low speeds, the HD rating is the most suitable.
The controller is used to control and monitor the frequency converter through the network.
Standard corresponding RS-485 communication (MITSUBISHI converter protocol, Modbus-RTU protocol) data transmission speed up to 115200bps. Be used with A8GT-C_BS as Can A8GT-C_EXSS-1Drive: MR-H_ACN series SSC-NET compatible AC servo.
Rated output: 5.0KW.
The servo controller can easily transfer the operation module and the field bus module through the automation interface,
At the same time using different fieldbus modules to achieve different control modes (RS485, RS232, optical fiber, InterBus, ProfiBus),,
And the contrrol mode of general inverter is single A6CON-P520.
The servo controller is directly connected with a rotary transformer or an encoder, which forms a closed loop of speed and displacement control.
The general inverter can only form an open loop cconntrol system A6CON-P520.
Servo controller of the control parameters (such as steady-state accuracy and dynamic performance) is better than the general inverter.
A6CON-P520 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=A6CON-P520&select=5
