4103 Earth position: 6h MENNEKES 4103
Brand:
Mennekes
Name: Cepex wall mounted receptacle
Model: 4103
Product Name:Cepex wall mounted receptacle
Part No.:4103.
Ampere:16A.
Poles:4p.
Voltage:400V.
Earth position: 6h.
Hertz 50-60Hz.
Protection type IP44.
screw terminals.
cable entry: 1 x M 25 with cable gland at top, 1 x M 25 to be cut out at the bottom, 1 x M 20 to be cut out at the back side, for cables 7 up to 13 mm Ø.
meeting DIN 18032 standards for ball rebound.
...More relevant models >>>>
Name: Cepex wall mounted receptacle
Model: 4103
Product Name:Cepex wall mounted receptacle
Part No.:4103.
Ampere:16A.
Poles:4p.
Voltage:400V.
Earth position: 6h.
Hertz 50-60Hz.
Protection type IP44.
screw terminals.
cable entry: 1 x M 25 with cable gland at top, 1 x M 25 to be cut out at the bottom, 1 x M 20 to be cut out at the back side, for cables 7 up to 13 mm Ø.
meeting DIN 18032 standards for ball rebound.
