>> AGF Series OMRON AGF Series Arc grounding, short circuit capability, high reliability
AGF Series OMRON AGF Series Arc grounding, short circuit capability, high reliability
Brand:
OMRON
Name: High voltage ground relay
Model: AGF Series
High voltage ground relay AGF type, anti wave interference,
Arc grounding, short circuit capability, high reliability.
The anti - interference ability is strong, and can safely correspond to the arc grounding fault.
The grounding relay and the zero phase converter ZCT can be separately used.
(any combination is not more than JIS of the specified error range, and therefore can be used)
Can carry out fine current adjustment, easy to coordinate.
In all the models set up alarm terminal.
