>> AJ65SBTB1-32TE1 Choose from a rich product lineup MITSUBISHI AJ65SBTB1-32TE1 Transistor output module
AJ65SBTB1-32TE1 Choose from a rich product lineup MITSUBISHI AJ65SBTB1-32TE1 Transistor output module
Brand:
MITSUBISHI
Name: Transistor output module
Model: AJ65SBTB1-32TE1
Output type: transistor output, source.
Output points: 32 points.
OFF leakage current: 0.1mA.
Output protection function: No.
Rated load voltage / current: DC12V/DC24V/0.5A.
External connection: 1 wire.
According to the external connection mode and the external equipment input and output specifications,
Choose from a rich product lineup.
Finger protection through the upper part of the terminal,
The human body will not be exposed to live parts,
Therefore, the terminal station type remote I/O module can be directly mounted to the machine tool.
