C200H-IP007 OMRON C200H-IP007 Peripheral Interface Unit

Model: C200H-MR431.
Description: RAM, 4 K words, battery back-up. no clock.Connects Power Supply Adapter and SYSMAC NET Link Unit.
For 1 Unit.UM: 31.2K words.
DM: 6K words.
EM: 6Kx3 banks(18K) words.
Instruction processing time (basic instructions): 0.1 µ.s min.
No. of I/O points: 880 points.
Max OMRON C200H-IP007. no.of con-necting Expansion I/O Racks: 2 Racks.
Max. no. of connecting High-density I/O Units(i C200H-IP007e., Group-2): Unavailable.
Max. no. of con-necting Special I/O Units: 10.
RS-232C: NO.Model: C200H-OC224.
No. of points: 8 pts.
Specifications: 2A, 250VAC/24VDC(For resistive loads)Independent commons.Name: SYSMAC LINK Module.
Model: C200HW-SLK24.
Communications method: N: N token bus.
Transmission method: Manchester code, base band OMRON C200H-IP007.
Transmission path: Bus.
Weight: 400 g max.8 pts, No-voltage contact. PNP.For 8-slot Backplane.Model: C200H-AD001.
Input points: 4.
Voltage input: 1 to 5V or 0 to 10 V.
Current input: 4 to 20 mA.Model: C200HW-COM05-V1.
Specifications: Two RS-232C ports and a protocol macro function.A memory card suitable for Phoenix PCM+3.2 and one of thefollowing Bus Connection Units is required OMRON C200H-IP007.
No PC card is provided with the Unit.Name: PID Control Module.
Model: C200H-PID02.
Output: Voltage output.Model: C200H-ID501.
No. of inputs: 32 pts.
Specifications: 5 VDC.Name: Controller Link Module.
Model: C200HW-CLK21.
Communications method: N: N token bus OMRON Peripheral Interface Unit.
Code Manchester: codeModel: C200H-B7A12.
I/O points: 32 input points or 30 input points and 2 error inputs.
Weight: 300g max OMRON Peripheral Interface Unit. Power supply voltage: DC100V.
Note: operation with output contacts.
Power supply unit.
The power supply of the CPU rack is supplied by the power supply unit.
The following power units are available for selection.
C200HW-PA204 (voltage: AC100-120V/AC200-240V)
C200HW-PA204S (voltage: AC100-120V/AC200-240V)
C200HW-PA204R (voltage: AC100-120V/AC200-240V)
C200HW-PD024 (voltage: DC24V)
In the past, PC connected to a measurement equipment or componentss must be given to the ASCII unit or BASIC unit to write a communication program OMRON Peripheral Interface Unit C200H-IP007.
Now, PC C200HX/HG/HE is installed on the communication protocol macro function,
Can be configured to these communicaations procedures through the PMCR instruction to the ladder program,
With this function system can be easily connected with a wide range of components OMRON C200H-IP007.
