CJ1W-SCU21-V1 OMRON CJ1W-SCU21-V1

Unit type: CJ1 Special I/O Units.
Product name: Analog Output Unit.
I/O points: 4 inputs ; 2 outputs.
Signal range selection:
Set separately for each input and output.
Signal range, Resolution: 1 to 5 V,
0 to 5 V, 0 to 10 V, -10 to 10 V,
4 to 20 mA.
Resolution: 1/4,000 (Settable to 1/8,000) OMRON CJ1W-SCU21-V1.
Conversion period: 1 ms/point,
(Settable to 500 μs/point).
Accuracy at ambient temperature of 25°C:
Voltage: ±0 CJ1W-SCU21-V12% of F.S. Current: ±0.2% of F.S;
Voltage: ±0.3% of F.S. Current: ±0.3% of F.S.
External connection: Removable terminal block.
External power supply: 24 VDC +10% -15%, 140mA max.
No. of unit numbers allocated: 1.
Current consumption: 5V, 0.58A; 24V, --.
Standards: UC1, N, L, CE OMRON CJ1W-SCU21-V1.
Consistent Microsecond Throughput:
Models with Direct Conversion Join the Lineup.
Analog Input Units for converting analog input,
signals into binary data.
Analog Output Units for converting binary ,
data into analog output signals. Product name: Transistor Output Units.
Specifications: Output type, Sourcing;
I/O points, 8outputs;
Maximum switching capacity, 24VDC,
2AShort-circuit protection;
Commons, 4 points, 1 common;
External connection, Removable terminal block OMRON CJ1W-SCU21-V1.
No. of words allocated: 1 word.
Current consumption: 5V, 0.11A; 24V, --.
Standards: UC1, N, L, CE.
A Wide Range of Basic Output,
Units for High Speed Output,
and Different Applications OMRON Serial Communications Units.
These Output Units receive the ,
results of output instructions ,
from the CPU Unit and perform ON/OFF,
control for external devices OMRON Serial Communications Units.
High-speed Output models CJ1W-OD213 and,
CJ1W-OD234 can help to increase system.
throughput. I/O capacity/Mountable Units(Expansion Racks): 2, 560 points/40 Units (3 Expansion Racks max.).
Program capacity: 120K steps.
CJ1H-CPU66H Data memory capacity: 256K words(DM: 32K words, EM: 32K words × 7 bank) OMRON Serial Communications Units.
LD instructioProduct name: CJ-series I/O Control Unit.
Specifications: Mount one I/O Control Unit,
on the CPU Rack when connecting one or,
more Expansion Racks.
Connecting Cable: CS1W-CN@@3 Expansion,
Connecting Cable CConnected Unit:
CJ1W-II101 I/O Interface Unit,
Mount to the right of the CPU Unit CJ1W-SCU21-V1.
Current consumption: 5V , 0.02A;
24V, --.
Standards: UC1, N, L, CE.
Expand CJ/NJ-series with These Units.
To expand a CJ/NJ-series Controlller,
connect an I/O Control Unit to the CPU Rack,
and I/O Interface Unit to the Expansion Rack,
and connect the two Units with I/O Expansion Cable OMRON CJ1W-SCU21-V1.
