CS1H-CPU64H OMRON CS1H-CPU64H

Unit type: CS1 Special I/O Units.
Name: CompoBus/S Master Unit.
Specifications: Communications,
functions, Remote I/O communications;
No. of I/O points, 256 max.
(128 inputs and 128 outputs), 128 max.
(64 inputs and 64 outputs);
Max. Units mountable per CPU Unit, 95, 96.
No. of unit numbers allocated: 2; 1 OMRON CS1H-CPU64H.
Current consumption: 5V, 0.15A; 26V, --.
Standards: U, C, CE CS1H-CPU64H
CompoBus/S is a high-speed I/O bus. Unit type: CS1 Special I/O Units.
Product name: Isolated-type,
Thermocouple Input Units.
points Input: 4 inputs.
Signal range selection:
Set separately for each input.
I/O type: R, S, K, J, T, L, B.
Conversion speed: 250 ms/4 inputs.
Externa connection: Removable erminal block OMRON CS1H-CPU64H.
No. of unit numbers allocated: 1.
Current consumption: 5V, 0.25A; 26V, --.
Standards: UC1, CE.
Provides the functionality of isolators,
power supplies, signal converters,
and other devices.
The Analog Input Unit converts analog,
input signals such as 1 to 5 V or 4 to 20mA,
into digital values, and takes the values,
scaled in industrial units, and transfers,
it to the CPU Unit as the process value OMRON CS1H-CPU64H.
Because of this, no ladder program is required,
at the CPU Unit for scaling.
The Analog Output Unit converts analog output set,
values from the CPU Unit to analog output signals,
such as 4 to 20 mA or 1 to 5 V, and outputs them OMRON .
The built-in functions, such as measurement value,
alarms, rate-of-change calculations, and square roots,
have enabled major savings in cost and space compared,
with previous systems OMRON .
High-resolution Models and 8-point Input Models are,
also available.
By combining the Units, logging/monitoring.
systems can be constructed,
or the Units can be used together with LCBs/LCUs,
to construct complete process control systems OMRON .
Parameters can be easily displayed and set in an,
easy-to-understand form without special tools. Name: CS1D CPU Backplane.
Specificatioons: Applicable systems,
Duplex CPU, Dual I/O Expansion System only;
Number of Power Supply Units,
2 Units max CS1H-CPU64H. (for duplex operation);
Number of I/O Units, 5 Units max.
(including the I/O Control Units).
Current consumption:: 5V system, 1 OMRON CS1H-CPU64H. 20A;
26V system, --.
Standards: UC1, CE.
Redundant CPU Units , Power Supply Units ,
Communications Units ,
and Expansion I/O Cables.
