CS1W-MD261 Programmable Controllers OMRON CS1W-MD261

Specifications: Two RS-232C Ports.Unit type: CS1 CPU Bus Unit.
Product Name: MECHATROLINK-II,
compatible Motion Control Unit.
Specifications: Control modes: Position,
speed, or torque control via MECHSTROLINK-II,
Control axes: 32 axes max.
(30 physical axes, 2 virtual axes).
Internal programming language: Special,
motion control language OMRON CS1W-MD261.
No. of unit numbers allocated: 1 CS1W-MD261
Current consumption: 5V, 0.80A; 26V, --.
Standards: UC1, CE.
Improve Equipment Design Efficiency and,
Shorten Tact Time.
Control Servos for up to 16 axes in a,
motion network with one Position Control,
Unit that supports MECHATROLINK-II .
MECHATROLINK-II is a registered trademark,
of the MECHATROLINK Members Association OMRON CS1W-MD261. Control method: Semiclosed loop with automatic trapezoid or S-curve acceleration/deceleration.
Control output signals: Analog.
Controlled axes: 2 axes max.Unit type: CS1 Basic I/O Units.
Product name: DC Input Unit.
Specifications: 24 VDC, 6 mA,
32 inputs.
Mountable Racks: CPU Rack, CS1W-BC,
@@3,YES, @@2, YES;
C200HX/HG/HE Expansion I/O Rack, No.
CS1 Expansion Rack, CS1W-BI,@@3,YES,
@@2, YES; CS1 Long distance Expansion Rack,
Yes; SYSMAC BUS Slave Rack, No OMRON CS1W-MD261.
Words required: (I/O bits: CIO 0000 to CIO 0319), 2 words.
Current consumption: 5V system, 0.15A;
26 V system, --.
Standards: UC1, N, L, CE.
Multi-application Controllers:
From High-performance Machine C,
Highly Reliable Process Control OMRON Programmable Controllers. Unit type: CS1 Basic I/O Units.
Product name: DC Input Unit OMRON Programmable Controllers.
Specifications: 24 VDC, 7 mA,
64 inputs.
Mountable Racks: CPU Rack, CS1W-BC,
@@3,YES, @@2, YES;
C200HX/HG/HE Expansion I/O Rack, No.
CS1 Expansion Rack, CS1W-BI,@@3,YES,
@@2, YES; CS1 Long distance Expansion Rack,
Yes; SYSMAC BUS Slave Rack, No.
Words required: (I/O bits: CIO 0000 to CIO 0319), 4 words OMRON Programmable Controllers.
Current consumption: 5V system, 0.15A;
26 V system, --.
Standards: UC1, N, L, CE.
Multi-application Controllers:
From High-performance Machine C,
Highly Reliable Process Control. Unit type: CS1 Special I/O Units.
Product name: Power Transducer Input Unit.
Input points : 8 inputs.
Signal range: 0 to 1 mA, ±1 mA.
Conversion speed (resolution):
200ms/8 inputs.
Externa connection: Removable erminal block.
No. of unit numbers allocated: 1.
Current consumption: 5V, 0.15A; 26V, 0.08A.
Standards: UC1, CE.
Provides the functionality of isolators,
power supplies, signal converters,
and other devices.
The Analog Input Unit converts analog,
input signals such as 1 to 5 V or 4 to 20mA,
into digital values, and takes the values,
scaled in industrial units, and transfers,
it to the CPU Unit as the process value.
Because of this, no ladder program is required,
at the CPU Unit for scaling.
The Analog Output Unit converts analog output set,
values from the CPU Unit to analog output signals,
such as 4 to 20 mA or 1 to 5 V, and outputs them.
The built-in functions, such as measurement value,
alarms, rate-of-change calculations, and square roots,
have enabled major savings in cost and sspace compared,
with previous systems CS1W-MD261.
High-resolution Models and 8-point Input Models are,
also available.
By combining the Units, logging/monitoring.
systems can be constructed,
or the Units can be used together with LCBs/LCCUs,
to construct complete process control systems OMRON CS1W-MD261.
Parameters can be easily displayed and set in an,
easy-to-understand form without special tools.
