>> DRT2-ID16SL OMRON DRT2-ID16SL Screw-less structure eliminates tightening work
DRT2-ID16SL OMRON DRT2-ID16SL Screw-less structure eliminates tightening work
Brand:
OMRON
Name: Screw-less Clamp Terminals with Transistors
Model: DRT2-ID16SL
Short/disconnection detection: Not supported.
Specifications: Inputs, NPN (+ common), 16 points.
I/O connections: Clamp terminals.
Rated internal circuit power supply voltage:
Supplied from communications connector.
Rated I/O power supply voltage: 24 VDC.
Reduced Wiring and Labor on Factory Sites with Screw-less Terminal Wiring.
Screw-less structure eliminates tightening work.
Detachable terminal blocks for easier maintenance.
Single-step wiring by simply inserting pole terminals.
