G3PF Series OMRON Solid State Relays with Built-in Current Transformer OMRON G3PF Series

Standard certification: No.
Action indicator: No.
Applicable load of output: DC5 2A ~ 110V.
Input rated voltage: DC4 ~ 24V.
Insulation: photo coupler.
Zero trigger function: No.
And the MY type of the same shape of the G3F series of new international standard certification (-VD type).
Achieved UL, CSA, EN (VDE certification) standard certification OMRON G3PF Series. (type -VD)
Socket terminal type of same size with MY (2 pole type) G3PF Series
A model with an action indicator to check the status of the input. Type: Models with LED Indicator (See note 2.).
Terminals: Plug-in.
Contact form: DPDT.
Internal connections (See note 3.): Non-standard.
With mechanical indicator and lockable test button.
Coil ratings: AC/DC OMRON G3PF Series.
New Super MK Relays.
Models with Latching Lever Added to the Series.
Same mounting and internal wiring as the previous Super.
MK Relays.
Built-in mechanical indicator enables checking contact operation.
Two modes can be used to check circuits for models with latching lever.
Nameplate provided on models with latching lever.
All materials are RoHS compliant.
UL and IEC (TÜV) certification OMRON G3PF Series. Name: Short-circuit Unit.
Current flow: 30 A, 40 A.
Applicable SSR: G3PA-430B-VD, G3PA-240B-VD.
Refer to Safety Precautions for All Solid State Relays.
Allows 2-wire Switching of 3-phase Power.
Ideal for 2-wire switching of 3-phase heaters.
Improve ease of operation. Number of phases: Three-phase.
Insulation method: Phototriac coupler OMRON Solid State Relays with Built-in Current Transformer.
Operation indicator: Yes (yellow).
Rated input voltage: 12 to 24 VDC OMRON Solid State Relays with Built-in Current Transformer.
Zero cross function: Yes.
Type: Screw mounting.
Applicable load: 25 A, 200 to 480 VAC.
Number of pole: 3.
Compact, Slim-profile SSRs with Heat Sinks.
Solid State Contactors for Three-phase.
Heaters Reduced Installation Work.
with DIN Track Mounting.
RoHS compliant.
Surge pass protection improved surge dielectric strength,
for output currents OMRON Solid State Relays with Built-in Current Transformer. (OMRON testing).
Slim design with 3-phase output and built-in heat sinks.
DIN Track mounting types and screw mounting types are available.
All DIN Track mounting types mount to DIN Track.
(applicable DIN Track: TR35-15Fe (IEC 60715)).
Conforms to UL, CSA, and EN standards (TÜV certification). Classification: Relay with Auxiliary Contact Block.
Structure: 4 poles + 2 poles.
Contact configuration: Relay, 3PST-NO/SPST-NC; Auxiliary Contact Block, SPST-NO/SPST-NC.
Rated Voltage: 12, 24 VDC.
Compact Electromagnetic Contactors That.
Switch 40 A at 440 VAC.
One pole carries 40 A.
UL 508 and UL 840 NC contacts (resistive 40 A 480 VAC, 60 Hz, 80,000 operations).
EN 60947-4-1 NC contacts (AC1 40 A 440 VAC, 50/60 Hz, 80,000 operations).
Ideal for supply power to industrial inverters, servo drivers, and other devices,
and switching power to motors and other equipment.
The maximum load capacity of 160 A when using 4-pole parallel connections.
EN 60947-4-1 certification for mirror contact mechanism obtained by combiining,
the Relay with an Auxiliary Contact Block G3PF Series.
Conforms to European PV standard (VDE0126).
Approx. 30% less operation noise than a standard electromagnetic contactor.
(Approx. 100 dB reduced to approx. 70 dB.)
Approx. 50% thhe volume of a standard electromagnetic contactor,
to help downsize control panels OMRON G3PF Series.
According to OMRON investigation of IIEC-AC1 50 A specifications.
