Operation/resetting system: Time-limit operation/self-resetting.
Operation mode: ON-delay operation.
Terminal: 8-pin round socket.
Time-limit contact: SPDT.
Instantaneous contact: SPDT.
Mounting: Surface mounting/track mounting; Flush mounting.
DIN-sized (48 x 48, 45 x 75 mm) Timer with.
Digital Setting and LCD Display.
Dual power supplies for free AC/DC.
Eight operation modes selectable with one unit.
seconds to 9,990 hrs.
Four external signal inputs.
remaining time.
Conforms to UL, CSA, and CE marking.
Input type: NPN/ voltage pulse input type.
Event input terminal 5 points (S-TMR, HOLD, RESET) is equipped with.
External power 80mA DC12V.
Note: K3HB-RPB-A, K3HB-RNB-A is not equipped with event input.
DeviceNet; DeviceNet:--.
96 (W) * 48 (H * 95mm) depth.
Power supply voltage: AC/DC24V.
Digital rotating pulse meter with high speed measurement for 50kHz OMRON H3CA-8H .
Action determine the color, can switch the green / Red 2 kinds of color display
H3CA-8H
Measurement of 50kHz high speed pulse.
Rotary encoder and a variety of ON/OFF pulse signals, the most up to 50kHz of high-speed pulse measurement.
Supply voltage: 12 to 24 VDC.
6-digit time counter: Light gray.
DIN 48 x 24-mm Total Counter/Time Counter,
with Easy-to-read Displays and Water and,
Oil Resistance Equivalent to IP66 OMRON H3CA-8H .
High-visibility, negative transmissive LCD display with 8.5-mmhigh characters and, built-in red LED backlight at low power.
consumption.
IP66 with oil resistance and NEMA 4 protection achieved by,
unifying the front with the case and by using oil-resistant parts,
and materials.
Compact (80 mm) body.
Just change a switch setting for either an NPN or PNP input OMRON H3CA-8H .
Supports both external resetting and manual resetting.
Finger-protection terminal block cover prevents electrical shock,
and conforms to VDE0106, Part 100.
Certified for UL and CSA safety standards OMRON Solid-state Timer.
Complies with EMC standards (EN 61326) and CE Marking. Supply voltage: 24, 100 to 120, 200 to 230 VAC; 12, 24, 48, 100 to 110, 125 VDC OMRON Solid-state Timer.
Time-limit contact: DPDT.
Short-time range model (0.1 s to 10 min).
Miniature Timer with Multiple Time Ranges,
and Multiple Operating Modes.
UL listed when used with a Push-In Plus Terminal Block Socket.
Conforms to CSA, CE Marking, LR, and CCC.
Black design with power supply terminals on top and contact output,
terminals on bottom OMRON Solid-state Timer.
Standard multiple operating modes and multiple time ranges.
Pin configuration compatible with MY Power Relay.
Minimizes stock. Type: H7CX-A Series.
Classification: Preset counter.
Configuration: 1-stage preset counter; Total and preset counter.
External connections: 11-pin socket.
Settings: 1-stage.
Display digit: 6 digits.
Outputs: Contact output (SPDT).
Power supply voltage: 100 to 240 VAC.
Ultra-compact Counter Provides More,
Complete Functionality.
Basic Features.
Short body with depth of only 59 mm (for 12 to 24-VDC Models with,
Screw Terminals).
Better readability with character height of 12 mm on 4--digit models,
and 10 mm on 6-digit models H3CA-8H .
The present value display characters can be switched between red,
green, and orange.
Safety and Reliability.
New set value limit and counter functions have been added.
Other Features.
Front Panel can be changed to white or light gray OMRON H3CA-8H .
New models with two tachometer inputs and two tachometer outputs have,
been added to the series.
