HF-SP702B Application example: MITSUBISHI HF-SP702B

Motor series: flat type, medium and small power.
Rated output power: 0.75kw.
Rated speed: 3000r/min.
Whether to bring the brakes: with.
Shaft end: Standard (straight).
Protection level: IP65 (IP67).
Features: flat type design makes this more suitable for installation in space.
Application examples: robot, food manufacturing machinery MITSUBISHI HF-SP702B.
High resolution encoder 131072p/rev (17 bit) HF-SP702B
The encoder with high resolution ensures excellent performance and stability at low speed.
All motor dimensions are the same as before and all are compatible with the wiring. MITSUBISHI motor universal AC servo amplifier MELSERVO-J3 series.
Rated output: 0.6kw.
Interface type: CC-Link communication type (built-in positioning function) MITSUBISHI HF-SP702B.
Power specification: single phase AC200V.
Positioning operation by setting position and rotational speed data in the positioning table and receiving the start signal from the main controller.
The setting of the position and speed of the positioning table, as well as the start and stop operation can be completed through CC-Link communication.
By using the MR-J3-D01 extension IO unit, the DI/O instruction can be used to select and locate the table MITSUBISHI HF-SP702B.
(CC-Link can not be used for MR-J3-D01 communications).
With built-in positioning function of the servo amplifier, can be set through the CC-Link communications and speed data. (corresponding to the CC-Link version: Ver MITSUBISHI Medium inertia power servo motor. 1.10)
Can be achieved through the CC-Link communications to start, stop and monitoring and other operations MITSUBISHI Medium inertia power servo motor.
Serial communication reduce wiring.
Distributed servo control system can be built by CC-Link communication.
The parameters of unit MR-PRU03 (optional) the parameter setting, operation and monitoring more convenient.
The servo amplifier can be used for speed control operation.
When the two stations are occupied, the speed can be set directly by the remote register MITSUBISHI Medium inertia power servo motor. Type: HF-SE servo motor, medium inertia power.
Rated output power: 1.0kw.
Rated speed: 2000r/min.
Electromagnetic brake: there.
Oil seal: No.
Servo motor can make control speed, position accuracy is very accurate,
The voltage signal can be converted to torque and speed to drive the control object.
Servo motor rotor speed is controlled by the input signal, and can quickly response,
In an automatic control system, used as an actuator,
With electromechanical time constant, high linearity, initiating voltage characteristics,
The signal can be converted into a motor shaft on the angular displacement or angular velocity output.
Divided into DC and AC servo motor two major categories, the main features are,
When the signal voltage is zero, the rotation speed increases with the increase of torque.
Wide use.
Machining equipment and machine tool feed.
Used for food, packaging equipment and feeding device.
For textile machinery, etc..
Can improve the performance of equipment.
Servo amplifier terminals are used to reduce the required wiring time.
The connector is located in front of the servo amplifier, which is convenient for cable connection.
The gain adjustment can be easily carried out by the real-time automatic tuning function.
High performance and easy to operate, reduce work load.
Enhanced system cost performance.
High performance, high pprecision positioning (servo motor encoder resolution: 131072) HF-SP702B.
High response.
Suppression of vibration by adaptive vibration suppression control.
Using personal computer and servo setup software to optimize tuning.
Has 2 types of interfaces:
Position control and speed control with pulse train interface MITSUBISHI HF-SP702B.
The analog input interface is used for speed control and torque control.
