SGDV-2R8A01B000FT001 YASKAWA Best use servo unit SGDV-2R8A01B000FT001

Sigma -v series servo unit SGDV.
Maximum applicable motor capacity: 7.5kw.
Power supply voltage: three phase AC400V.
Design sequence: B type.
Interface: analog voltage, pulse sequence type (rotary servo motor).
Matching (hardware): base mounting type (standard).
Excellent mechanical properties, do the best in the master!
Easy and efficient work, is no longer a dream,
Sigma -v series servo drive, you can make your dreams come true YASKAWA SGDV-2R8A01B000FT001 SGDV-2R8A01B000FT001
Sigma -v series is equipped with new free adjustment function,
Broke the common sense of the servo drive "can''t run smoothly without adjusting",
To achieve a pass that is to use.
A new type of advanced automatic tuning function Sigma -v series,
The installation time can be shortened, and the performance of the machine can be fully played YASKAWA SGDV-2R8A01B000FT001. High performance, use the best type of servo unit (purpose type).
Maximum applicable motor capacity: 0.2kw.
Power supply voltage: single phase AC100V.
Interface: MECHATROLINK-II communication command type (rotary servo motor).
Design sequence: B.
Hardware specifications: paint.
Function: pressure feedback control function YASKAWA SGDV-2R8A01B000FT001.
Use the best type of sigma -V-FT series
According to different uses, there are 5 equipped with a convenient function of the servo unit models.
FT001 (vibration suppression function to upgrade specifications): by strengthening the vibration suppression function, shorten the positioning time YASKAWA Best use servo unit.
FT003 (pressure feedback function): high precision pressure control, to promote the high performance of the device YASKAWA Best use servo unit.
FT005 (support for rotary table purposes): with the rotation of the coordinate function and fixed point through the output function, can be smooth and high-precision control of rotary table.
FT006 (fixed point through the output function): no need to pass through the upper device can be set through the output (Chu Fa) YASKAWA Best use servo unit.
FT008 (absolute value system support): the absolute value of the system can be constructed by any upper controller. Sigma -V series servo motor SGMAV.
Rated output: 0.05kw (50W).
Power supply voltage: AC200V.
Serial encoder: 20 bit Delta (standard).
Design sequence: standard.
Shaft end: straight shaft with keyway, with screw (optional).
Optional: with oil seal.
Super power rate.
Small capacity.
Ultra low inertia
Instantaneous maximum torque (rating 300%).
Equipped with a high resolution serial encoder (20 bit).
Max speed up to 6000r\/min.
Variety is complete (50W ~ 1.0kw, with hold brake).
Use example:
Semiconductor manufacturing equipment,
Placement machine,
Punch printed circuit board,
Robot，
Handling machinery，
Food processing machinery.
Rating and specifications:
Rated time: continuous.
Vibration level: V15.
Insulation resistance: DC500V, 10M, or above.
Using ambient temperature: 0 ~ 40 degrees C.
Excitation mode: permanent magnet type.
Installation metthod: flange type SGDV-2R8A01B000FT001.
Heat resistance grade: B.
Insulation withstand voltage: AC1500V1 minutes.
Protection mode: fully enclosed self cooling type IP65 (except shaft through part).
The use of environmental humidity: 20 ~ 80%% (not dew) YASKAWA SGDV-2R8A01B000FT001.
Connection mode: direct connection.
Rotation direction: clockwise direction (CCW) rotation at the load side under the direction of rotation
