3658 MENNEKES Door Switches 3658

Product Name:Panel mounted receptacle with TwinCONTACT
Part No.:1744.
Ampere:32A.
Poles:5p.
Voltage:110V.
Earth position :4h.
Hertz50-60 Hz.
Connection technology:Screwless - TwinCONTACT.
Contact: standrad.
Protection type IP44 MENNEKES 3658.
screwless spring terminals.
suitable for through wiring 3658
flange: 73,5 x 64 mm.
fixing hole spacing: 60 x 52 mm.
20° inclination.Product Name:Plug SCHUKO®
Part No.:10754.
Ampere :16A.
Poles:2p+E MENNEKES 3658.
Voltage:230V .
Shutter:no.
Connection technology:Screw terminals MENNEKES 3658.
Contact:standard .
Protection type:IP44.
screw terminals.
with combined PE-conductor acc. to german and french-belgian standard.
with grommet.
for cables up to 3 x 2.5 mm², up to H07RN-F.Product Name:Connector
Part No.695A.
Ampere :32A.
Poles:2P.
Voltage:40-50V.
Hertz:50-60 Hz.
Earth position:12 h.
Connection technology:Screw terminals.
Contact:standard.
Protection type:IP44 3658.
screw terminals 3658.
with grommet.
