3769 MENNEKES Door Switches 3769

Product Name:AMAXX® receptacle combination
Part No.:920005.
Fitted with:1 CEE 16A, 5p, 400V
2 SCHUKO® 16A, 230V.
Fusing:1 MCB 16A, 3p, D
2 MCB´s 16A, 1p, C.
Pre-fuse max.:63A.
InA:32A.
RDF:1.
Connection/feeder cable:for 1 cable up to 5 x 10 mm² MENNEKES 3769.
Enclosure size:260 x 225 mm (H x W) 3769
Protection type IP44.
pre-wired for installation.
hinged to the side.
enclosure and insert made of AMAPLAST MENNEKES 3769.
fusing behind a transparent cover . Product Name:Cepex panel mounted receptacle
Part No.:4119.
Ampere:32A.
Poles:4p.
Voltage:500V.
Earth position: 7h.
Hertz 50-60Hz.
Protection type IP44.
screw terminals.
also suitable for installation in cable ducts and columns MENNEKES 3769.
meeting DIN 18032 standards for ball rebound.Product Name:Cepex panel mounted receptacle
Part No . :4115.
Ampere:16A.
Poles:5p.
Voltage:400V.
Earth position: 6h.
Hertz 50-60Hz.
Protection type IP44.
screw terminals.
also suitable for installation in cable ducts and columns.
meeting DIN 18032 standards for ball rebound.Product Name:Panel mounted receptacle with TwinCONTACT
Part No.:1805.
Ampere:32A.
Poles:4p.
Voltage:400V.
Earth position :6h.
Hertz 50-60Hz.
Connection technology:Screwless - TwinCONTACT.
Contact: standrad.
Protection type IP67.
screwless spring terminals.
suitable for through wiring.
20° inclination.
receptacles are designed for adding an auxiliary contact switch.Product Name::Wall mouunted receptacle
Part No 3769.:7616.
Ampere:32A.
Poles:5p.
Voltage:400V.
Earth position :6h.
Hertz50-60 Hz.
Connection technology:screw terminals.
Contact: standard.
Protection type:IP44 3769.
screw terminals.
for horizontal installation.
switched.
mechanical DUO-interlock.
receptacles can be padlocked.
3769 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=3769&select=5
