829 MENNEKES 829

Product Name:AMAXX® receptacle combination
Part No.:930038A.
Fitted with:1 CEE 32A, 5p, 400V
4 french/belg. standard 16A, 2p+E, 230V.
Fusing:1 RCD 40A, 4p, 0.03A
1 MCB 32A, 3p+N, C
1 MCB 16A, 1p+N, C
1 off button
1 indicator light.
Pre-fuse max:40A.
InA :38A MENNEKES 829.
RDF:0 8297.
Connection/feeder cable:for 1 cable up to 5 x 25 mm².
Enclosure size:390 x 225 mm (H x W).
Protection type IP44.
pre-wired for installation MENNEKES 829.
hinged to the side .
enclosure and insert made of AMAPLAST.
fusing behind a transparent cover.Product Name:Connector PowerTOP®
Part No.:3891.
Ampere:32A.
Poles:4p
Voltage:400V.
Earth position:6h.
Hertz 50-60Hz.
Connection technology:Screw terminals.
Contact:nickel plated contacts, highly heat resistant contact carrier MENNEKES 829.
Protection type IP67.
screw terminals.
with highly heat resistant contact carrier.
cable gland and external cable grip.Product Name:Wall mounted inlet
Part No.:340.
Ampere:16A.
Poles:5p.
Voltage:110V.
Earth position:4h.
Hertz 50-60Hz.
Connection technology:Screw terminals.
Contact:standard.
Protection type IP44.
screw terminals.
enclosure base with stamped recess for quick cutting out.Product Name:Plug ProTOP
Part No.:659.
Ampere:16A.
Poles:5p.
Voltage:500V.
Earth position: 7h.
Hertz 50-60Hz 829.
Connection technology:Screw terminals.
Contact:standard.
Protection type IP44.
screw terminals 829.
cable gland and sealing.
strain relief and protection against kinking.
enclosure with thread lock and safety slide.
829 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=829&select=5
