Product Name:Wall mounted receptacle
Part No.:7226.
Ampere:32A.
Poles:5p.
Voltage:400V.
Earth position :6h.
Hertz50-60 Hz.
Connection technology:screw terminals.
Contact: standrad.
Protection type IP44.
screw terminals 834 Price.
switched.
mechanical DUO-interlock.
RCD (0.03A)
834
other leakage current ratings on request.
receptacles can be padlocked.Product Name:Connector PowerTOP® Xtra
Part No.:14229.
Ampere:63A.
Poles:4p
Voltage:400V.
Earth position:6h.
Hertz 50-60Hz.
Connection technology:Screw terminals, SoftCONTACT 834 Price.
Contact:nickel plated contacts, highly heat resistant contact carrier.
Protection type IP67.
screw terminals.
with rubberised grip area.
frame terminals.
with SoftCONTACT.
with highly heat resistant contact carrier 834 Price.
cable gland and sealing.
strain relief and protection against kinking .
enclosure with thread lock.
two safety slides.Product Name:Plug ProTOP
Part No.:152A.
Ampere:16A.
Poles:4p.
Voltage:400V.
Earth position: 6h.
Hertz 50-60Hz.
Connection technology:Screw terminals.
Contact:standard.
Protection type IP44.
screw terminals.
cable gland and sealing.
strain relief and protection against kinking.
enclosure with thread lock and safety slide.Product Name:Cepex wall mounted receptacle
Part No.:4104.
Ampere:16A.
Poles:4p.
Voltage:500V.
Earth position: 7h.
Hertz 50-60Hz.
Protection type IP44.
screw terminals.
cable entry: 1 x M 25 with cable gland at top, 1 x M 25 to be cut out at the bottom, 1 x M 20 to be cut out at the back side, for cables 7 up to 13 mm Ø.
meeting DIN 18032 standards for ball rebound.Product Name:Inlet SCHUKO®
Part No.:10864.
Ampere :16A.
Poles:2p+E.
Voltage:230V.
Connection technology:Screw teerminals .
Contact :standard MENNEKES 834.
Protection type: IP68.
screw terminals.
with combined PE-conductor acc. to german and french-belgian standard. .
with bayonet ring MENNEKES 834.
protective cap attached by a strap.
one threaded M 20 cable entry at top and one blind M 20 cable entry (can be cut out) at bottom.
834 Operation manual/Instructions/Model selection sample download link:
