Proface EXM-AMO1HT

Video-Mix module (32000 color, video input x 4 channel, analog RGB input x 1 channel, analog RGB output x 1 channel, VGA/SVGA)Used to output the image signal from the host computer to GPInput voltage: DC24V.
Screen size: 7 inch widescreen.
Display type (resolution):65536 color TFT (WVGA 800 x 480 pixels) Proface .
Touch panel type: analog resistance.
Memory: 16MB (internal memory), SRAM128KB (backup memory) EXM-AMO1HT
Ethernet interface: 1.
Serial port: RS-232C * 1, RS-422/485 * 1.
SD card slot (max 32GB):1.
USB interface: Type-A x (2) USB 1, Mini-B USB (2) x 1.
Replaceable battery: yes.
Alarm analysis function block: No.
Panel opening size:
Wide 204 Proface . 5 x high 159.5mm (+1/0mm).
Panel thickness: 1.6-5mm, chamfer radius is less than R3 .
Coating models: none.
Easily connect a variety of USB devices
Can be easily connected to the man-machine interface serial controller, EZ series accessories, bar code reader and USB memory.
Remote data acquisition and management
Human machine interface, which is installed on the production machine,
With EX Microsoft software combined with Office Pro-Server and SQL and other standard PC software,
Can be simple and economical to establish a set of data management system, and effectively improve the quality of production and efficiency Proface . PNP output type.
Display size: 5.7 inches.
Resolution: 320 x 240 pixels (QVGA).
LCD: monochrome.
Color: 16 levels of gray.
Ethernet interface: No.
Serial port: 1.
CANopen interface: No.
USB (host):1.
USB (device): none.
Built in DIO input: 16 points.
Built in DIO output: 16 points.
Built in AIO input: No.
Built in AIO output: No.
Common DIO:2 point high speed counter (with synchronous output) pulse capture input, pulse output, PWM output.
Special DIO: No.
Expansion module EX module: up to 3.
Expansion module CANopen module: 63 stations.
Controller memory size: EPROM 132KB FLASH (equivalent to 15000 steps (up to 60000 steps).
Integrated design.
Adopt integrative design, compact structure,
When the installation is only required to open a hole in the panel 22mm.
The display module or the control module can be easily replaced when the fault is eliminated.
Using remote monitoring software GP-Viewer or data acquisition software EX Pro-Server,
Can easily monitor the production scene of the man-machine interface screen, or release production orders and real-time data collection.
Flexible installation.
The control module can be installed on the DIN guide rail by using the split installation cable,
And the display module is installed in other locations.
Display module occupies a small space, even if the space is limited, but also can be flexible to install.
Connect various control devices.
Pro-face human machine interface can be connected to a variety of industrial controllers, including PLC, motion controller, robot and other equipment.
Remote HMI Pro-face.
Natural connection production line and tablet PC or smart phone. By adding APP,
True implementation of mobile operations without loss of any operational performance.
Directly confirm the cause of the failure of the phone, as far as possible not to the scene on the recovery of the machine running.
In order to meet the needs of users for small control devices, Pro-face integrated control and operation functions in the human computer interface.
In short, is to indicate the lights, instruments and other display devices and switches, buttons and other operational functions to integrate into a compact PLC.
In addition to reducing wiring and saving space, the design also greatly reduces the use of electrical components,
Which ensures the long service life of the equipment.
The compact models are equipped with standard I/O, and they can be used as a special I/O.
High / low pulse with maximum 100kHz and maximum 65kHz of the high speed counter can be achieved by the advanced control.
Strong I/O interface not only supports the need to switch and indicator light equipment, but also supports the need for sophisticated positioning of complex equipment.
CANopen network
LT4000M supports data exchange with a variety of remote devices through the CANopen, easy to achieve economic and easy to use system design.
Can choose standard I/O module, also can choose action or control module and other more advanced products in complex application.
Use EX GP-Pro to easily test and debug the project.
EX GP-Pro simulation is a kind of offline simulation function, with the help off this function,
No neeed to connect the man-machine interface, you can test the operation of the screen and the logic program Proface EXM-AMO1HT.
Compact size.
The volume is small but the display is fresh and bright, can create a rich and readable operation picture.

Thhe control function of the whole and the digital I/O, analog I/O, analog temperature input and USB, serial port and Ethernet communication interface Proface EXM-AMO1HT.
EXM-AMO1HT Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=EXM-AMO1HT&select=5
