Sale GP3000-VM01 Proface GP3000-VM01

Provide dust proof and moisture proof function when installing GP3000H conversion adapter to hard panel.Screen protection cover (1 pieces) for protecting screen against pollution of man-machine interfaceCFast cards (32GB, SLC,) inserted in the CFast slot for storage.For 5.7 inch models, for the 5.7 inch man-machine interface into the LT series (A/B/B+/C/H Type) of the opening GP3000-VM01. Input voltage: DC24V GP3000-VM01
Screen size: 7.5 inches.
Display type (resolution):65536 color TFT (VGA 640 x 480 pixels).
Touch panel type: analog resistance.
Memory: 32MB (internal memory), SRAM320KB (backup memory), SRAM64KB (variable area).
Ethernet interface: 1 GP3000-VM01.
Serial port: RS-232C * 1, RS-422/485 * 1.
SD card slot (max 32GB):1 .
USB interface: Type-A x (2) USB 1, Mini-B USB (2) x 1.
Replaceable battery: yes.
Alarm analysis function block: yes.
Panel opening size:
Wide 204.5 x high 159.5mm (+1/0mm).
Panel thickness: 1.6-5mm, chamfer radius is less than R3.
Back mounted model: there.
Enhance the display effect.
Meet a number of standards to support a wide range of applications
The coating components are widely used in various working environments, and are in line with the international standards GP3000-VM01.
Remote data acquisition and management.
Human machine interface, which is installed on the production machine,
With EX Microsoft software combined with Office Pro-Server and SQL and other standard PC software,
Can be simple and economical to establish a set of data management system, and effectively improve the quality of production and efficiency. Backup battery for time and data backup (1).Specifications: DC24/ coated models.
Display type: TFT color LCD.
Display size: 12.1 inches.
Resolution: 800 x 600 pixels (SVGA).
Display color: 65536 color (no flash) /16384 color (3 speed flicker).
Backlight: cold cathode tube (replaceable).
Brightness adjustment: 8 level adjustment can be carried out by touch panel.
Variable area: 64KB SRAM (using lithium battery).
Program area: EPROM 132KB FLASH.
Step number: equivalent to 15000 steps.
Touch panel type: resistance type (analog).
Can improve the efficiency of the 5 functions.
Using EX GP-Pro can easily create a clear picture and save the creation time.
Screen and logic programming software EX GP-Pro interface is very friendly,
The drag and drop feature makes the software innterface easy to operatee Proface GP3000-VM01.
EX GP-Pro powerful features, such as 3D simulation components, image fonts and simulation functions,
Even beginners can easily and quickly grasp how to create a picture.
Rich sample images can reduce programming time.
Pro--faace provides a large number of sample images and 3D parts,
So you can easily create a beautiful and intuitive picture, in order to save editing time Proface GP3000-VM01.
GP3000-VM01 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=GP3000-VM01&select=5
