Proface FN-XY16SC41

Disposable film (5 sheets / sets) for protecting screen against contamination of human computer interface.Portable GP2000H series models accessories, RS-232 cable with D-Sub connector (10 meters).Input voltage: DC24V.
Screen size: 5.7 inches.
Display type (resolution):65536 color TFT display LCD (QVGA 320 x 240 pixels) Proface .
Touch panel type: analog resistance.
Memory: 16MB (internal memory), SRAM320KB (backup memory), SRAM64KB (variable area) FN-XY16SC41
Ethernet interface: 1.
Serial port: RS-232C * 1, RS-422/485 * 1.
SD card slot (max 32GB):1.
USB interface: Type-A x (2) USB 1, Mini-B USB (2) x 1.
Replaceable battery: yes.
Alarm analysis function block: yes Proface .
Panel opening size:
Wide 118.5 x high 92.5mm (+1/0mm) .
Panel thickness: 1.6-5mm, chamfer radius is less than R3.
Back mounted model: there.
Simplify troubleshooting.
Using alarm analysis function, can grasp the cause of the fault in time.
Just a few clicks, you can set the alarm analysis screen,
Analysis of the status data of the register related to the alarm.
Remote monitoring and control Proface .
Using remote monitoring software EX GP-Viewer,
Can be from a running PC system Windows remote monitoring of the production scene of the man-machine interface screen . Analog /PNP output type.
Display size: 5.7 inches.
Resolution: 320 x 240 pixels (QVGA).
LCD:TFT.
Color: 65536 color.
Ethernet interface: 1.
Serial port: 1.
CANopen interface: 1.
USB (host):1.
USB (equipment):1.
Built in DIO input: 12 points.
Built in DIO output: 6 points.
Built in AIO input: 4 points.
Built in AIO output: 2 points.
Common DIO:2 point high speed counter (with synchronous output) pulse capture input.
Dedicated DIO:2 point pulse output, PWM output.
Expansion module EX module: none.
Expansion module CANopen module: 63 stations.
Controller memory size: EPROM 132KB FLASH (equivalent to 15000 steps (up to 60000 steps).
CANopen network
LT4000M supports data exchange with a variety of remote devices through the CANopen, easy to achieve economic and easy to use system design.
Can choose standard I/O module, also can choose action or control module and other more advanced products in complex application.
Compact size.
The volume is small but the display is fresh and bright, can create a rich and readable operation picture.
The control function of the whole and the digital I/O, analog I/O, analog temperature input and USB, serial port and Ethernet communication interface.
Integrated design.
Adopt integrative design, compact structure,
When the installation is only required to open a hoole in the panel 22mm .

The display module or the control module can be easily replaced when the fault is eliminated Proface FN-XY16SC41.
Flexible installation.
The control module can be installed on the DIN guide rail by using the split installation cable,
And the disspllay module is installed in other locations Proface FN-XY16SC41.
Display module occupies a small space, even if the space is limited, but also can be flexible to install.
FN-XY16SC41 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=FN-XY16SC41&select=5
