CS1W-B7A22 Programmable Controllers and open-collector or line-driver outputs OMRON CS1W-B7A22

Unit type: CS1 Special I/O Units.
Product name: Isolated-type,
Thermocouple Input Units.
points Input: 4 inputs.
Signal range selection:
Set separately for each input.
I/O type: R, S, K, J, T, L, B.
Conversion speed: 250 ms/4 inputs.
Externa connection: Removable erminal block.
No. of unit numbers allocated: 1 OMRON CS1W-B7A22.
Current consumption: 5V, 0.25A; 26V, --.
Standards: UC1, CE CS1W-B7A22
Provides the functionality of isolators,
power supplies, signal converters,
and other devices.
The Analog Input Unit converts analog,
input signals such as 1 to 5 V or 4 to 20mA,
into digital values, and takes the values,
scaled in industrial units, and transfers,
it to the CPU Unit as the process value OMRON CS1W-B7A22.
Because of this, no ladder program is required,
at the CPU Unit for scaling.
The Analog Output Unit converts analog output set,
values from the CPU Unit to analog output signals,
such as 4 to 20 mA or 1 to 5 V, and outputs them.
The built-in functions, such as measurement value,
alarms, rate-of-change calculations, and square roots,
have enabled major savings in cost and space compared,
with previous systems OMRON CS1W-B7A22.
High-resolution Models and 8-point Input Models are,
also available.
By combining the Units, logging/monitoring.
systems can be constructed,
or the Units can be used together with LCBs/LCUs,
to construct complete process control systems OMRON Programmable Controllers.
Parameters can be easily displayed and set in an,
easy-to-understand form without special tools. Unit type: CS1 CPU Bus Unit OMRON Programmable Controllers.
Product Name: MECHATROLINK-II,
compatible Motion Control Unit.
Specifications: Control modes: Position,
speed, or torque control via MECHSTROLINK-II,
Control axes: 32 axes max.
(30 physical axes, 2 virtual axes).
Internal programming language: Special,
motion control language.
No. of unit numbers allocated: 1 OMRON Programmable Controllers.
Current consumption: 5V, 0.80A; 26V, --.
Standards: UC1, CE.
Improve Equipment Design Efficiency and,
Shorten Tact Time.
Control Servos for up to 16 axes in a,
motion network with one Position Control,
Unit that supports MECHATROLINK-II .
MECHATROLINK-II is a registered trademark,
of the MECHATROLINK Members Association. Unit type: CS1 Basic I/O Units.
Product name: Triac Output Units.
Specifications: 250 VAC, 0.5 A max.
16 outputs.
Mountable Racks: CPU Rack, CS1W-BC,
@@3, Yes, @@2, Yes;
C200HX/HG/HE Expansion II/O Rack, No CS1W-B7A22.
CS1 Expansion Rack, CS1W-BI,
@@3, Yes, @@2, Yes;
CS1 Long distance Expansion Rack, Yes;
SYSMAC BUS Slave Rack, No.
Words required: 1 word.
Current consumption: 5V system, 0.23 max.
(0.07+0.02 ×number of ON poiints);
26 V system, -- OMRON CS1W-B7A22.
Standards: UC, N, L, CE.
Multi-application Controllers:
From High-performance Machine C,
Highly Reliable Process Control.
