>> FR-F842-09620-2-60 Three phase 400V grade frequency converter MITSUBISHI FR-F842-09620-2-60 Power: 355kw
FR-F842-09620-2-60 Three phase 400V grade frequency converter MITSUBISHI FR-F842-09620-2-60 Power: 355kw
Brand:
MITSUBISHI
Name: Rectifying partial off type frequency converter
Model: FR-F842-09620-2-60
MITSUBISHI inverter series: FR-F842.
Voltage level: three phase 400V.
Power: 450kw.
SLD converter rated current: 962A.
Structure and function: the rectification part is off type.
Type: CA.
Substrate coating: have.
Energy saving by high efficiency motor.
Reduce standby power consumption.
DC24V external power supply, the input MC signal can be stopped after the motor for the OFF, in the motor drive for the ON.
Standby power management can be carried out by means of frequency converter to realize the power consumption reduction of standby time.
According to the temperature of the inverter cooling fan, the operation of the inverter can be controlled.
According to the operating conditions of the inverter cooling fan output the corresponding signal,
Therefore, the inverter and other built-in fan and inverter cooling fan synchronous operation.
Can reduce the power consumption in the stop.
