>> FR-HEL-H11K MITSUBISHI FR-HEL-H11K AC reactor
FR-HEL-H11K MITSUBISHI FR-HEL-H11K AC reactor
Brand:
MITSUBISHI
Name: DC reactor
Model: FR-HEL-H11K
Power: 11kw.
Purpose: to suppress the power harmonics.
Improve the power factor, reduce the input side of the high harmonic current.
Make sure that this option is installed in the FR-A820-03800 (75K) and FR-A840-02160 (75K) and above capacity and above capacity.
At the same time the installation options in the use of 75kW and above motor. (the IP55 series has a built-in DC reactor.)
According to the motor power used to select the DC reactor.
(when the inverter capacity is greater than the motor capacity, is still based on the motor capacity to choose.)
...More relevant models >>>>
