>> HC-SF103 MITSUBISHI HC-SF103 Medium inertia medium capacity motor
HC-SF103 MITSUBISHI HC-SF103 Medium inertia medium capacity motor
Brand:
MITSUBISHI
Name: Medium inertia medium capacity motor
Model: HC-SF103
Motor series: medium inertia, medium capacity.
Using a serial absolute / incremental encoder.
Rated output power: 1.0kw.
Rated speed: 3000rpm.
With the brake: without.
Shaft end: straight shaft.
When the AC servo motor has no control voltage, only the pulsating magnetic field generated by the excitation winding is generated in the stator, and the rotor is still not moving.
When the control voltage is controlled, a rotating magnetic field is generated in the stator, and the rotor rotates in the direction of the rotating magnetic field,
In the case of constant load, the speed of the motor varies with the size of the control voltage,
When the phase of the control voltage is reversed, the servo motor will reverse.
...More relevant models >>>>
Name: Medium inertia medium capacity motor
Model: HC-SF103
Motor series: medium inertia, medium capacity.
Using a serial absolute / incremental encoder.
Rated output power: 1.0kw.
Rated speed: 3000rpm.
With the brake: without.
Shaft end: straight shaft.
When the AC servo motor has no control voltage, only the pulsating magnetic field generated by the excitation winding is generated in the stator, and the rotor is still not moving.
When the control voltage is controlled, a rotating magnetic field is generated in the stator, and the rotor rotates in the direction of the rotating magnetic field,
In the case of constant load, the speed of the motor varies with the size of the control voltage,
When the phase of the control voltage is reversed, the servo motor will reverse.
