>> R16CPU Input / output points: 4096 points MITSUBISHI R16CPU
R16CPU Input / output points: 4096 points MITSUBISHI R16CPU
Brand:
MITSUBISHI
Name: Programmable logic controller CPU
Model: R16CPU
Operation control mode: stored procedure repeated operation.
Input / output points: 4096 points.
Program capacity: 160K step.
Multi CPU system for high precision motion control
The high speed control can be realized by executing the parallel control program and the parallel processing of multi CPU high speed communication.
The communication cycle between multi CPU has been synchronized with the motion control time, which can reduce the redundant control time.
After installing the 3 motion CPU modules, the maximum of 96 axes can be used for servo control.
Program capacity of up to 1200K.
Multi CPU system for high precision motion control.
The built-in CPU module support 2 Gigabit Network port.
Database functions to facilitate data management.
Extended SRAM card with built-in security function.
Can be carried out a variety of motion control (position, speed, torque, advanced synchronous control, etc.).
In line with the international safety standards (13849-1 PL e ISO, IEC 61508 SIL 3) security CPU.
The most suitable for C/C++ language programming from the computer / computer environment for transplantation.
