CA5-WPG10-01 Proface CA5-WPG10-01

Screen protection cover (1 pieces) for protecting screen against pollution of man-machine interfaceInput voltage: DC24V.
Screen size: 5.7 inches.
Display type (resolution):65536 color TFT display LCD (QVGA 320 x 240 pixels).
Touch panel type: analog resistance.
Memory: 16MB (internal memory), SRAM320KB (backup memory), SRAM64KB (variable area) Proface CA5-WPG10-01.
Ethernet interface: 1.
Serial port: RS-232C * 1, RS-422/485 * 1 CA5-WPG10-01
SD card slot (max 32GB):1.
USB interface: Type-A x (2) USB 1, Mini-B USB (2) x 1.
Replaceable battery: yes.
Alarm analysis function block: yes.
Panel opening size:
Wide 118.5 x high 92.5mm (+1/0mm).
Panel thickness: 1 Proface CA5-WPG10-01. 6-5mm, chamfer radius is less than R3.
Serial isolation models: there .
Simplify troubleshooting.
Using alarm analysis function, can grasp the cause of the fault in time.
Just a few clicks, you can set the alarm analysis screen,
Analysis of the status data of the register related to the alarm.
Remote monitoring and control.
Using remote monitoring software EX GP-Viewer,
Can be from a running PC system Windows remote monitoring of the production scene of the man-machine interface screen Proface CA5-WPG10-01. To prevent the connection of disconnected USB cable fastening clips (Mini-B USB, 1 interface, 5 / set)"Compact, RS-422/485, green / orange / red three color LED backlight.
Input voltage: DC24V.
Screen size: 3.4 inches.
Display type (resolution):STN monochrome LCD (200 x 80 pixels).
Touch panel type: analog resistance.
Memory: 2.2MB (internal memory).
Ethernet interface: No.
Serial port: RS-485 (isolation).
SD card slot (max 32GB): No.
USB interface: Type-A x (2) USB 1, Mini-B USB (2) x 1.
Replaceable battery: no (rechargeable battery).
Alarm analysis function block: No.
Coating models: none.
The use of drag and drop operations, can be easily shared between the man-machine interface and the control program of the symbolic register data,
Make the programming process intuitive and efficient.
In addition, the common and special control function is defined as the function block, which simplifies the design of the control system. .
The man-machinne interface picture is directly connected with the control program, which can realize the efficient programming CA5-WPG10-01.
6 Display Module 2 host module, can realize the 12 kinds of "intelligent platform".
Modular design, display module and thhe host module can be split,
Therefore can be replaced respectively CA5-WPG10-01.
Display module and host module free combination, function and size of flexible. "
CA5-WPG10-01 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=CA5-WPG10-01&select=5
