PFXZCBWG61 Proface PFXZCBWG61

When the man-machine interface is installed to the fixed panel to provide dust proof and moisture proof function. (1)Output points: 16 point relay (a-connect).
Rated output voltage.
External connection: 10 pin terminal connector.
Public end design: 4 point /1 public end. Input voltage: DC24V.
Screen size: 10 Proface PFXZCBWG61. 4 inches.
Display type (resolution):65536 color TFT display LCD (VGA 640 x 480 pixels).
Touch panel type: analog resistance PFXZCBWG61
Memory: 32MB (internal memory), SRAM320KB (backup memory), SRAM64KB (variable area).
Ethernet interface: 1.
Serial port: RS-232C * 1, RS-422/485 * 1.
SD card slot (max 32GB):1.
USB interface: Type-A x (2) USB 1, Mini-B USB (2) x 1 Proface PFXZCBWG61.
Replaceable battery: yes.
Alarm analysis function block: yes .
Panel opening size:
Wide 259 x high 201mm (+1/0mm)
Panel thickness: 1.6-5mm, chamfer radius is less than R3.
Coating models: there.
Meet a number of standards to support a wide range of applications
The coating components are widely used in various working environments, and are in line with the international standards Proface PFXZCBWG61.
Remote data acquisition and management.
Human machine interface, which is installed on the production machine,
With EX Microsoft software combined with Office Pro-Server and SQL and other standard PC software,
Can be simple and economical to establish a set of data management system, and effectively improve the quality of production and efficiency . Specifications: DC24/M (Multimedia) class models.
Display type: TFT color LCD (Gao Liangdu).
Display size: 12.1 inches.
Resolution: 800 x 600 pixels (SVGA).
Display color: 65536 color (no flash) /16384 color (3 speed flicker).
Backlight: cold cathode fluorescent lamp replacement: return to repair.
Brightness adjustment: 8 level adjustment can be carried out by touch panel.
Variable area: 64KB SRAM (using lithium battery).
Program area: EPROM 132KB FLASH.
Step number: equivalent to 15000 steps.
Touch panel type: resistance type (analog).
Rich sample images can reduce programming time.
Pro-face provides a large number of sample images and 3D parts,
So you can easily create a beautiful and intuitive picture, in order to save editing time.
Can improve the efficiency of the 5 functionss .
Using EX GPP-Pro can easily create a clear picture and save the creation time PFXZCBWG61.
Screen and logic programming software EX GP-Pro interface is very friendly,
The drag and drop feature makes the software interface easy to operate.
EX GP-Pro powerful feeatures, such as 3D simulation components, image fonts and simulation functions,
Even beginners can easily and quickly grasp how to create a picture PFXZCBWG61.
PFXZCBWG61 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=PFXZCBWG61&select=5
