"Size: 5.7 inches.
Display type: STN pseudo color LCD.
Resolution: 320 x 240 pixels (QVGA).
Display color: 256 color (no flash) /64 color (3 speed flicker).
Power supply: DC24V.
Interface: USB (TYPE-A), RS-232C, RS-422/485 (MPI).
Brightness adjustment: 8 level adjustment can be carried out by touch panel PFXZGPWGR1 Price.
You can easily and intuitively set the address by dragging and dropping the mouse.
In addition, click on the use of the address can be displayed on the screen number and part number
PFXZGPWGR1
Click the part number to jump to the screen using the widget.
The same software supports all 3000 series of Pro-face man-machine interface PFXZGPWGR1 Price.
From the screen to create the programming, the functions are simple and easy to use .
Learn a software, master all the skills.
Support efficient image creation.
ID management and operation log reduces downtime.
Improve the operation mode, reduce the cost and workload.
Analysis of failure causes according to the operation log.
Check register status on historical trend chart.
Drag and drop functionality makes the software interface easier to operate PFXZGPWGR1 Price.
A variety of components to provide a variety of components, easy to create a beautiful picture .
In addition, there are a variety of 256 color components can be used.
Using the alarm log to quickly check and display the alarm message and register value, it is easier to find the cause of the fault.
Register value will be recorded when the alarm is issued.
Therefore, the state of the register and its value can be obtained while acquiring the alarm message.
A comparison of the data is helpful to find the cause of the fault.
These "sample parts" can be used directly, and the design time is greatly reduced.
According to ID number of easy access to the operation log, through the analysis of the operation to improve production efficiency.
Use ID based on the number of authorized mode of operation, can be recorded when, who performed the operation.
Using this data, you can analyze the causes of all the faults that have occurred. "Compact, serial RS-232C, green / orange / red three color LED backlight.
Input voltage: DC24V.
Screen size: 3.4 inches.
Display type (resolution):STN monochrome LCD (200 x 80 pixels).
Touch panel type: analog resistance.
Memory: 2.2MB (internal memory).
Ethernet interface: No.
Serial port: RS-232C.
SD card slot (max 32GB): No.
USB interface: Type-A x (2) USB 1, Mini-B USB (2) x 1.
Replaceable battery: no (rechargeable battery).
Alarm analysis function block: No.
Coating models: none.
The use of drag and drop operations, can be easily shared between the man-machine interface and the control program of the symbolic register data,
Make the programming process intuitive and efficient.
In addition, the common and special control function is defined as the function block, which simplifies the design of the control systeem .
The man-machine innterface picture is directly connected with the control program, which can realize the efficient programming Proface PFXZGPWGR1.
6 Display Module 2 host module, can realize the 12 kinds of "intelligent platform".
Modular design, display module annd the host module can be split,
Therefore can be replaced respectively Proface PFXZGPWGR1.
Display module and host module free combination, function and size of flexible.
PFXZGPWGR1 Operation manual/Instructions/Model selection sample download link:
