Proface PFXZGPFSR7W1

Input voltage: DC24V.
Screen size: 7 inch widescreen.
Display type (resolution):65536 color TFT (WVGA 800 x 480 pixels).
Touch panel type: analog resistance.
Memory: 16MB (internal memory), SRAM128KB (backup memory).
Ethernet interface: 1.
Serial port: RS-232C * 1, RS-422/485 * 1.
SD card slot (max 32GB):1 Proface .
USB interface: Type-A x (2) USB 1, Mini-B USB (2) x 1.
Replaceable battery: yes.
Alarm analysis function block: No PFXZGPFSR7W1
Panel opening size:
Wide 204.5 x high 159.5mm (+1/0mm).
Panel thickness: 1.6-5mm, chamfer radius is less than R3.
Coating models: none.
Easily connect a variety of USB devices
Can be easily connected to the man-machine interface serial controller, EZ series accessories, bar code reader and USB memory Proface .
Remote data acquisition and management
Human machine interface, which is installed on the production machine,
With EX Microsoft software combined with Office Pro-Server and SQL and other standard PC software,
Can be simple and economical to establish a set of data management system, and effectively improve the quality of production and efficiency Proface . Used to interface the main machine output serial port (D-sub 9 pin concave type) directly connected to the RS-422 terminal block . The main body module and the separate display module are used for connecting the main machine module and the separate display module in the DIN guide rail.Controller DIO (NPN model):6 point type NPN input, 2 point NPN type output, connector: 12 pin.
Specification: DC24/C (control) level models.
Display type: TFT color LCD.
Display size: 5.7 inches.
Resolution: 320 x 240 pixels (QVGA).
Display color: 65536 color (no flicker) /16384 color (flashing).
Brightness adjustment: cold cathode lamp (backlight lamp replacement: return to repair).
Touch panel type: resistance type (analog).
Easily upgrade.
GP/ST series supports GP series of all models of the screen data, including the first generation of the GP10 series.
GP product family to maintain the size of the opening of the panel compatibility, to facilitate easy replacement.
Simulated running status on PC.
Use PC simulation function, do not need to transfer the picture to GP,
You can check all the functions of GP on the PC - including the screen operation, D script, logical script.
Providing operation and maintenance instructions through video mode, which can save maintenance cost.
The operation and maintenance instructions provided by the video mode can make any operator easy to master the operation method.
No need to open the control panel, through the PLC to monitor the GP program.
Through the data through the GP function, you can easily debug the ladder program and adjust the data due to changes in the production line by GP easily.
Use USB memory or CF card backup monthly and daily
Recording function using USB memory or CF card can easily improve the efficiency of daily and monthly.
The use of CSV data conversion function can be modified on the PLC GP settings.
Rich sample images can reduce programming time.
Pro-face provides a large number of sample images and 3D parts,
So you can easily create a beautiful and intuitive picture, in order to save editing time.
Data transmission using USB memory.
In the production site using USB memory can be easily transferred to the production line change and change the screen data.
Can improve the efficiency of the 5 functions.
Using EX GP-Pro can easily create a clear picture and save the creation time.
Screen and logic programming software EX GP-Pro interface is very friendly,
The drag and drop feature makes the software interface easy to operate.
EX GP-Pro powerful features, such as 3D simulation components, image fonts and simulation functions,
Even beginners can easily and quickly grasp how to create a picture.
Error visualization.
The controller is directly connected to the GP, and the key error informmation of the controller can be displayed on the GP by using the sample unit Proface PFXZGPFSR7W1.
Remote operation and monitoring in the Office
In the office or other remote side can monitor the production site of the GP screen.
Without picturee eediting or programming, you can achieve real-time management and monitoring, and now, you can also provide more efficient remote maintenance control Proface PFXZGPFSR7W1.
PFXZGPFSR7W1 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=PFXZGPFSR7W1&select=5
