Proface FN-AD02AH41 FN-AD02AH41

DIO model /NPN output type.
Display size: 3.5 inches.
Resolution: 320 x 240 pixels (QVGA).
LCD:TFT.
Color: 65536 color.
Ethernet interface: 1.
Serial port: 1.
CANopen interface: 1.
USB (host):1.
USB (equipment):1.
Built in DIO input: 20 points.
Built in DIO output: 10 points.
Built in AIO input: No.
Built in AIO output: No Proface FN-AD02AH41.
Common DIO:2 point high speed counter (with synchronous output) pulse capture input FN-AD02AH41
Dedicated DIO:2 point pulse output, PWM output.
Expansion module EX module: none.
Expansion module CANopen module: 63 stations.
Controller memory size: EPROM 132KB FLASH (equivalent to 15000 steps (up to 60000 steps) Proface FN-AD02AH41.
Compact size.
The volume is small but the display is fresh and bright, can create a rich and readable operation picture .
The control function of the whole and the digital I/O, analog I/O, analog temperature input and USB, serial port and Ethernet communication interface.
Integrated design.
Adopt integrative design, compact structure,
When the installation is only required to open a hole in the panel 22mm Proface FN-AD02AH41.
The display module or the control module can be easily replaced when the fault is eliminated .
Flexible installation.
The control module can be installed on the DIN guide rail by using the split installation cable,
And the display module is installed in other locations.
Display module occupies a small space, even if the space is limited, but also can be flexible to install.
Connect various control devices.
Pro-face human machine interface can be connected to a variety of industrial controllers, including PLC, motion controller, robot and other equipment.
Remote HMI Pro-face.
Natural connection production line and tablet PC or smart phone. By adding APP,
True implementation of mobile operations without loss of any operational performance.
Directly confirm the cause of the faailure of the phone, as far as possible not to the scene on the recovery of the machine running FN-AD02AH41.
CANopen network
LT4000M supports data exchange with a variety of remote devices through the CANopen, easy to achieve economic and easy tto use system design FN-AD02AH41.
Can choose standard I/O module, also can choose action or control module and other more advanced products in complex application.
FN-AD02AH41 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=FN-AD02AH41&select=5
